全自动超声波织带穿扣折尾机 Automatic Ultrasonic Ribbon Threading and Folding Machine
全自动超声波织带穿扣折尾机
Automatic Ultrasonic Ribbon Threading and Folding Machine
功能特点 Features
可适用于衣服配料，背包，手袋，鞋类及适合其他特殊用途
It can be used for clothing ingredients, backpacks, handbags, shoes and other special purposes
主要用于背包的织带穿扣车缝
It is mainly used for sewing the webbing of backpacks
全自动化作业,无需人手操作,自动作业流程,自动送带,自动送扣。自动折尾车缝。
Fully automated operation, no manual operation required, automatic operation process, automatic belt feeding, automatic buckle feeding
传统相比较机器缝制出来的产品更加标准美观
Compared to traditional machines, products sewn by machines are more standardized and aesthetically pleasing
系统设有缺料警报,可预设产品数量,完成产量自动停机
There is a shortage alarm in the system, which can preset the quantity of products and automatically shut down after completing the production
技术参数 Technical Parameters
|
型号model |
JS-CK/ZW-UT1 |
电压Welta |
AC220V |
|
气压Alr pressure |
0.5-0.6 MPa |
裁切方式 Cutting |
自动遍频超声波系统 Auto frequency tracing ultrasonic system |
|
功率Power |
1200W |
系统System |
可编程系统Programmable system |
|
驱动Drive |
伺服闭环系统Programmable system |
缝制Sewing |
打枣车Bartack machine |
|
感切角度 Cutting angle |
直裁 cut straight |
作业宽度 Working width |
长度100-1000MM对折长度10- 50MM Length 100-1000MM Folded length 10-50MM |
|
体积 Wolume |
长1600MM*宽750MM*高1450MMength 1600MM th 750MM He ht 1450MM |
重量Weight |
278KG |
|
产能 Capacity |
长度500MM为例，每分钟产能11-15条 11-15 pieces per minute for 500MM length (as an example) |
||
一人可同时操作多台主设备
One person can operate multiple master units simultaneously
